C2 Type Double Crank Presses

Machine type	C2-200
MODEL	V TYPE H TYPE
Capacity Tons	200
Rated tonnage point mm	6 3
Stroke Length mm	250 150
Stroke Per Minute S.P.M	25-45 35-70
Die height(S.D.A.U) mm	500
Slide adjustment mm	120
Bolster area(LR×FB) mm	2400×840
Bolster thickness mm	170
Slide area(LR×FB) mm	1850×650
Slide thickness mm	95
Hole of Slide mm	Ø50×3×Pitch375
Main Motor KW×P	15×4 15×4
Slide adjusting motor HP×P	2×4
The pressure of air supply kg/cm²	5-6
Precision	GB(JIS) 1ST CLASS
Weight Tons	27
Outline dimension	2620×2235×3849
Die cushion model Tons	双顶板双汽缸 2-Pad-2-Cylinder
Die cushion capacity Tons	10×2
Air pressure kg/cm²	6.75
Stroke Length mm	80
The area of the top tray of die cushion	540×350×2组

Standard Equipment	Optional Equipment
Hydraulic Overload protection Device	Die Cushion
Manual Grease Lubrication Device	Automatic Grease Lubrication Pump
Automatic Slide Adjustment Device	Light Curtain
Digital Readout Die Height	Knockout
Air Counter Balance Device	Die Light
CAM	BDC Sensor
Clutch&Brake Performance Monitoring	Foot Operation Device
SPM Showing While Slide Not In Motion	QDC(Die Lift/Die Arm/Die Clamper)
Maintance Instruction	Feeding Line
Air Outlet Device	Removable T-stand
Air Ejector Device
Overrun Protection Device
Inverter Motor
Misfeed Device
Main Motor Direction Control Device
Digital Stroke Counter
Pre-cut Counter
Pre-set Counter
Power Outlet
Anti Vibration Mount
Maintenance Toolbox
Operation Manual
