H2 Straight side double crank Presses

Machine type	H2-500
MODEL	S TYPE H TYPE
Capacity Tons	500
Rated tonnage point mm	9 5
Stroke Length mm	300 170
Stroke Per Minute SPM	20-30 30-45
Die height(S.D.A.U) mm	600 450
Slide adjustment mm	120
Slide area(LR×FB) mm	A	2700×1100×95
	B	3000×1100×95 L
	C	3300×1100×95 LL
Bolster area(LR×FB) mm	A	2900×1200×220
	B	3200×1200×220 L
	C	3500×1200×220 LL
Side opening mm	1000×550
Main motor KW×P	37×4
Sliding adjusting motor HP×P	7×4
Max.upper die weight kg	A	3400
	B	3800
	C	4200
Die cushion capacity Tons	14×2
The pressure of air supply Kg/cm2	6

Standard Equipment	Optional Equipment
Hydraulic Overload protection Device	Die Cushion
Manual Grease Lubrication Device	Automatic Grease Lubrication Pump
Automatic Slide Adjustment Device	Light Curtain
Digital Readout Die Height	Knockout
Air Counter Balance Device	Die Light
CAM	BDC Sensor
Clutch&Brake Performance Monitoring	Foot Operation Device
SPM Showing While Slide Not In Motion	Flywheel Brake
Maintance Instruction	Die Block
Air Outlet Device	QDC(Die Lift/Die Arm/Die Clamper)
Air Ejector Device	Feeding Line
Overrun Protection Device	Anti Vibration Mount
Inverter Motor
Misfeed Device
Main Motor Direction Control Device
Digital Stroke Counter
Pre-cut Counter
Pre-set Counter
Power Outlet
Ground Stand MEP
Removable T-stand
Maintenance Toolbox
Operation Manual
