CNC Vertical Gear Hobbing
G260 Vertical Gear Hobbing
- Max Processing Module of 6mm
- Tool Spindle Max Speed of 1500r/min
- 7-Axis Control with 4-Axis Simultaneous Motion
- Temperature-Controlled Cooling System (Oil Cooler)
- Precision Ball Screws and High-Rigidity Linear Roller Guides
Service Online:
|
Item
|
Specification (Unit)
|
|
Maximum Workpiece Diameter
|
∅260 mm
|
|
Maximum Workpiece Modulus
|
6 mm
|
|
Maximum Stroke of X Axis
|
200 mm
|
|
Maximum Stroke of Y Axis
|
160 mm
|
|
Maximum Stroke of Z Axis
|
300 mm
|
|
Range of Teeth Processed
|
3～750 teeth
|
|
Wheel Holder Rotational Angle
|
±45 degrees
|
|
Wheel Shaft Specifications
|
∅16, ∅22, ∅27,∅32, ∅40 mm
|
|
Maximum Wheel Specifications
|
∅130×180 mm
|
|
Type of Hobbing Spindle Taper Bore
|
BT40
|
|
Rapid Movement Speed of X Axes
|
9 m/min
|
|
Rapid Movement Speed of Z Axes
|
10 m/min
|
|
Workpiece Spindle
|
Rated Torque: 750 N.m
|
|
|
Max Speed: 150 r/min
|
|
Wheel Spindle Motor
|
Rated Torque: 382N.m
|
|
|
Rated power: 15 KW
|
|
|
Max Speed: 1500 r/min
|
|
Total Power Capacity of Machine
|
Current: 100A
|
|
|
Power: 30 kW
|
|
Air Source Requirements
|
Pressure: 0.5～0.7 MPa
|
|
|
Flow Rate: 200 L/min
|
|
Machine Space Requirement
|
2610×3450×3000 mm
|
|
Machine Net/Gross Weight
|
8000/8500 kg
|
VIEW MORE
|
Standard Accessories
|
Optional Accessories
|
|
CNC Hobbing Machine (Main Unit)
|
Secondary Tool Setting Device
|
|
Chip Conveyor
|
Tool Air Cooling Device
|
|
Hydraulic Station
|
Deburring Device
|
|
Leveling Blocks
|
External Tool Calibration Device
|
|
Leveling Screws
|
Automatic Fixture
|
|
Hex Thin Nuts
|
Automatic Loading and Unloading Device
|
|
Technical manual
|
Oil Mist Separator
|
|
%
