Item
|
Specification
|
|
Travel
|
|
|
X Axis (Left-Right Travel)
|
1400mm
|
|
Y Axis (Front-Back Travel)
|
700mm
|
|
Z Axis (Up-Down Travel)
|
700mm
|
|
Distance from Spindle Center to Column Guide Rail
|
725mm
|
|
Distance from Spindle Face to Worktable Surface
|
120-820mm
|
|
Worktable
|
|
|
Worktable Size
|
1500×700mm
|
|
T-Slot (Number × Size × Pitch)
|
5×18×150
|
|
Max Worktable Load
|
1400kg
|
|
Spindle
|
|
|
Spindle Taper (Model/Installation Size)
|
BT40/Φ150
|
|
Spindle Speed
|
8000 Belt rpm
|
|
Motor
|
|
|
Spindle Motor
|
11-15 Kw
|
|
X Axis Motor
|
3 Kw
|
|
Y Axis Motor
|
3 Kw
|
|
Z Axis Motor
|
3 Kw
|
|
Automatic Tool Change System
|
|
|
Tool Magazine Type
|
Disk-Type Tool Magazine
|
|
Tool Magazine Capacity
|
24 positions
|
|
Max Tool Diameter (Full / Adjacent Empty)
|
80/150mm
|
|
Max Tool Length
|
300mm
|
|
Max Tool Weight
|
8kg
|
|
Tool Holder Drawbar Specification
|
45°
|
|
Feed Rate
|
|
|
Max Cutting Feed Rate (Three Axes)
|
10m/min
|
|
Rapid Movement (Three Axes)
|
20/20/12m/min
|
|
Accuracy
|
|
|
Positioning Accuracy
|
±0.005mm
|
|
Repositioning Accuracy
|
±0.003mm
|
|
Others
|
|
|
Machine Weight
|
11000kg
|
|
Machine Dimensions (L/W/H)
|
4.0 / 3.6 / 3.3m
|
|
Power Capacity
|
35Kw
|
